🔧 Key Features

• Hydraulic Operation: Powered by the hydraulic system of your skid steer, allowing efficient and smooth chipping operations.

• Chipping Capacity: Handles timber up to 4 inches in diameter.

• Adjustable Hopper: Material intake hopper is adjustable, improving safety and feeding efficiency.

• Rotating Chute: Debris chute rotates, enabling you to direct chips where you want them.



  Attribute	Details
  Model	SSBX42S
  Horsepower Required	18–30 HP
  Chipping Diameter	4"
  Rotor Size	25"
  Hopper Opening	20" x 20"
  Feeding Housing Opening	4" x 10"
  Blades	4 Rotor Blades + 1 Fixed Blade
  Hydraulic Flow	11–16 GPM
  Oil Tube 1 Length	70-55/64"
  Oil Tube 2 Length	5-29/32"
  Drain Oil Tube Length	70-55/64"
  Overall Dimensions	57" x 49" x 76"





  ✅ Compatibility

  • Mounting: Universal skid steer Quick-Attach compatible.

  • Ideal for: Forestry, landscaping, farm use, and land clearing tasks.
